MV65213X | Separation BRN80/95-BFR110 GAC
Code: 1974705
ManufacturerGewiss
Catalog numberMV65213X
TypeCeiling-/wall luminaire
CategoryCeiling-/wall luminaire
EAN code3660612401090
Details
- •SEPARATION BRN80/95-BFR110 GAC
- •Luminaires
- •Ceiling-/wall luminaire
- •Minimum order quantity: 1 m
- •GEWISS
Technical specifications
Connection typeScrewed terminal
Protection classI
Conductor cross section0.52mm²
Outer diameter250mm
With movement sensorNo
Colour rendering index CRI80-89
Type of gridNone
With light sensorNo
Type of control gearLED operating device current-controlled
Suitable for wall mountingYes
Voltage typeAC
Suitable for emergency lightingNo
Light sharingSymmetric
Height/depth58mm
Lamp typeLED not exchangeable
Material housingAluminium
Suitable for suspended mountingNo
Material coverPlastic, structured
Light outletDirect
Number of poles3
Suitable for light line configurationNo
With control gearYes
Impact strengthIK08
Covering of the luminaire with thermally insulating material possibleNo
Emergency power supply integratedNo
With light sourceYes
Suitable for built-in mountingNo
Suitable for number of lamps1
Degree of protection (IP)IP65
Luminaire with limited surface temperature, sign "D“No
Colour of lightWhite
Photobiological safety according to EN 62471RG0
Colour temperature3000 - 3000K
Filament test according to IEC 60695-2-11750 °C - 30 s
With air slotsNo
Suitable for workplace according to EN 12464-1No
Rated luminous flux according to IEC 62722-2-11500lm
Suitable for surface mountingYes
Beam angleExtreme wide beam >80°
Type of wiringEnding
Rated ambient temperature according to IEC62722-2-1-20 - 50°C
Max. system power18W
Constant light output (CLO)No
Colour consistency (McAdam ellipse)SDCM5
IFTTT support availableNo
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming phase cut-offNo
Dimming DALINo
Dimming RFNo
Dimming mains voltage modulationNo
Dimming programmableNo
Dimming DMXNo
Dimming phase cut-onNo
Dimming manufacturer's proprietary systemNo
Dimming LineSwitchNo
Dimming potentiometer (integrated)No
Unified Glare Ratio (UGR)25
Luminaire efficacy83lm/W
Operation by BluetoothNo
Dimming Sine Wave ReductionNo
Light distributorDiffuser lens/optic/panel
Dimming Touch and DimNo
No dim functionYes
Dimming DSINo
Dimming with push-buttonNo
Dimming ZigbeeNo
Compatible with Apple HomeKitNo
Compatible with Google AssistantNo
Compatible with Amazon AlexaNo
Dimming DALI-2No
Luminous flux adjustableNo
Colour temperature adjustableNo
Max. number of luminaires per miniature circuit breaker C16193
Max. number of luminaires per miniature circuit breaker B16116
Exchangeable control gearNo
Beam angle adjustableNo
Compatible with CasambiNo
Surface protection housingPowder coating
Suitable for ceiling mountingYes
Power factor0.9
Colour housingBlack
Nominal voltage220 - 240V
