GWS3158T | SMART3 LED 1600 1X58 Transp.
Code: 1975951
ManufacturerGewiss
Catalog numberGWS3158T
TypeCeiling-/wall luminaire
CategoryCeiling-/wall luminaire
EAN code8011564857483
Details
- •SMART3 LED 1600 1X58 TRANSP.
- •Luminaires
- •Ceiling-/wall luminaire
- •Minimum order quantity: 1 pcs
- •GEWISS
Technical specifications
Lamp holderOther
Protection classII
Connection typePush-in clamp
Conductor cross section2.5mm²
Width110mm
With movement sensorNo
Type of gridNone
Type of control gearLED operating device current-controlled
Voltage typeAC
Suitable for light line configurationNo
Lamp typeLED not exchangeable
Material housingPlastic
Suitable for wall mountingYes
With light sensorNo
Number of poles2
Suitable for emergency lightingNo
Length1600mm
Suitable for suspended mountingYes
Colour rendering index CRI80-89
Height/depth76mm
Emergency power supply integratedNo
Material coverPlastic, transparent
With light sourceYes
Light sharingSymmetric
Light outletDirect
Covering of the luminaire with thermally insulating material possibleNo
Impact strengthIK08
Degree of protection (IP)IP66
Luminaire with limited surface temperature, sign "D“Yes
With control gearYes
Suitable for number of lamps1
Suitable for workplace according to EN 12464-1No
Suitable for built-in mountingNo
Rated luminous flux according to IEC 62722-2-13400lm
Beam angleExtreme wide beam >80°
Nominal current280 - 280mA
Colour of lightWhite
Suitable for surface mountingYes
Constant light output (CLO)No
Colour temperature4000 - 4000K
IFTTT support availableNo
Type of wiringEnding
Max. system power26W
With air slotsNo
Dimming potentiometer (integrated)No
Dimming DMXNo
Dimming 1-10 VNo
Dimming DALINo
Dimming manufacturer's proprietary systemNo
Dimming 0-10 VNo
Photobiological safety according to EN 62471RG0
Colour consistency (McAdam ellipse)SDCM3
Rated ambient temperature according to IEC62722-2-1-25 - 50°C
Filament test according to IEC 60695-2-11850 °C - 30 s
Dimming LineSwitchNo
Dimming phase cut-offNo
Dimming mains voltage modulationNo
Dimming phase cut-onNo
Luminaire efficacy131lm/W
Dimming Sine Wave ReductionNo
Dimming programmableNo
Light distributorReflector
Dimming RFNo
Dimming with push-buttonNo
No dim functionYes
Dimming ZigbeeNo
Unified Glare Ratio (UGR)25
Dimming Touch and DimNo
Dimming DSINo
Compatible with Google AssistantNo
Colour temperature adjustableNo
Luminous flux adjustableNo
Beam angle adjustableNo
Max. number of luminaires per miniature circuit breaker C1649
Dimming DALI-2No
Operation by BluetoothNo
Compatible with Amazon AlexaNo
Max. number of luminaires per miniature circuit breaker B1625
Compatible with Apple HomeKitNo
Suitable for ceiling mountingYes
Compatible with CasambiNo
Exchangeable control gearNo
Power factor0.9
Surface protection housingUntreated
Colour housingGrey
Nominal voltage220 - 240V
