GWS3236T30K | SMART3 LED 1200 2X36 TRANSP.30K
Code: 1975962
ManufacturerGewiss
Catalog numberGWS3236T30K
TypeCeiling-/wall luminaire
CategoryCeiling-/wall luminaire
EAN code8011564872554
Details
- •SMART3 LED 1200 2X36 TRASPAR.30K
- •Luminaires
- •Ceiling-/wall luminaire
- •Minimum order quantity: 1 pcs
- •GEWISS
Technical specifications
Protection classII
Number of poles2
With movement sensorNo
Lamp holderOther
Suitable for suspended mountingYes
Connection typePush-in clamp
Conductor cross section2.5mm²
Type of control gearLED operating device current-controlled
Width110mm
Colour rendering index CRI80-89
Voltage typeAC
Type of gridNone
Suitable for wall mountingYes
With light sensorNo
Max. system power40W
Length1200mm
Height/depth76mm
Material housingPlastic
Emergency power supply integratedNo
Lamp typeLED not exchangeable
Covering of the luminaire with thermally insulating material possibleNo
With light sourceYes
Suitable for emergency lightingNo
With control gearYes
Suitable for built-in mountingNo
Suitable for workplace according to EN 12464-1No
Colour temperature3000 - 3000K
Degree of protection (IP)IP66
Suitable for number of lamps1
Nominal current280 - 280mA
Suitable for light line configurationNo
Light outletDirect
Impact strengthIK08
Beam angleExtreme wide beam >80°
Suitable for surface mountingYes
Luminaire with limited surface temperature, sign "D“Yes
Light sharingSymmetric
Material coverPlastic, transparent
Rated luminous flux according to IEC 62722-2-14900lm
Colour of lightWhite
Colour consistency (McAdam ellipse)SDCM3
Type of wiringEnding
IFTTT support availableNo
Photobiological safety according to EN 62471RG0
Dimming potentiometer (integrated)No
Dimming phase cut-offNo
Dimming DALINo
Filament test according to IEC 60695-2-11850 °C - 30 s
Rated ambient temperature according to IEC62722-2-1-25 - 50°C
Dimming LineSwitchNo
Dimming DMXNo
Dimming 0-10 VNo
Dimming 1-10 VNo
Constant light output (CLO)No
Dimming mains voltage modulationNo
Dimming phase cut-onNo
Dimming manufacturer's proprietary systemNo
With air slotsNo
Dimming ZigbeeNo
Dimming programmableNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming RFNo
Dimming DSINo
Dimming with push-buttonNo
Operation by BluetoothNo
Exchangeable control gearNo
Light distributorReflector
Luminous flux adjustableNo
Compatible with Apple HomeKitNo
Beam angle adjustableNo
Compatible with Amazon AlexaNo
Compatible with CasambiNo
Max. number of luminaires per miniature circuit breaker C1649
Luminaire efficacy123lm/W
Colour temperature adjustableNo
Dimming DALI-2No
Suitable for ceiling mountingYes
Unified Glare Ratio (UGR)25
Max. number of luminaires per miniature circuit breaker B1625
Power factor0.9
Compatible with Google AssistantNo
No dim functionYes
Surface protection housingUntreated
Colour housingGrey
Nominal voltage220 - 240V
