Details
- •Luminaires
- •High bay luminaire
- •1 KOM
- •GEWISS
Technical specifications
Mounting methodPendant
Colour housingGrey
Colour rendering index CRI80-89
Connection typePush-in clamp
Voltage typeAC
ReflectorHigh-gloss
Type of control gearLED operating device current-controlled
Width253mm
Conductor cross section1.5mm²
Protection classI
Lamp holderNone
Number of poles3
Length383mm
Ball-proofYes
Material housingPlastic
Suitable for emergency lightingNo
Material reflectorPlastic
Reflector colourSilver
Lamp typeLED not exchangeable
Light sharingAsymmetric
Height/depth89mm
Impact strengthIK08
Nominal voltage220 - 240V
With protective coverYes
Emergency power supply integratedNo
With light sourceYes
Nominal current325 - 325mA
Beam angleWide beam 41-80°
Luminaire with limited surface temperature, sign "D“Yes
With control gearYes
Suitable for number of lamps1
Colour of lightWhite
Type of wiringEnding
Rated ambient temperature according to IEC62722-2-15 - 40°C
Constant light output (CLO)No
Photobiological safety according to EN 62471RG0
Filament test according to IEC 60695-2-11850 °C - 30 s
Colour consistency (McAdam ellipse)SDCM3
Dimming 0-10 VNo
Rated luminous flux according to IEC 62722-2-18900lm
Dimming 1-10 VNo
Dimming manufacturer's proprietary systemNo
Dimming phase cut-offNo
Dimming DMXNo
Dimming mains voltage modulationNo
Dimming LineSwitchNo
Dimming DALINo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming programmableNo
Dimming phase cut-onNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Max. number of luminaires per miniature circuit breaker C1617
Suitable for auxiliary lampNo
Dimming with push-buttonNo
No dim functionYes
Dimming DSINo
Max. number of luminaires per miniature circuit breaker B1610
Light distributorRefractor lens
Luminaire efficacy139lm/W
Operation by BluetoothNo
Colour temperature adjustableNo
Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq)90%
Exchangeable control gearYes
Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq)10%
Luminous flux adjustableNo
Beam angle adjustableNo
Dimming Sine Wave ReductionNo
Power factor0.9
Degree of protection (IP)IP66
Colour temperature4000 - 4000K
Max. system power64W
