GWS4421AC857 | SMART[4]HB 4M St.al.dali ASI.5700K
Code: 1976942
ManufacturerGewiss
Catalog numberGWS4421AC857
TypeHigh bay luminaire
CategoryHigh bay luminaire
EAN code8034035063305
Details
- •SMART[4]HB 4M ST.AL.DALI ASI.57K
- •Luminaires
- •High bay luminaire
- •Minimum order quantity: 1 pcs
- •GEWISS
Technical specifications
Width504mm
Protection classI
Mounting methodPendant
Lamp holderNone
Connection typePush-in clamp
Voltage typeAC
Colour housingGrey
Colour rendering index CRI80-89
Conductor cross section1.5mm²
Type of control gearLED operating device current-controlled
Height/depth114mm
Material housingPlastic
Lamp typeLED not exchangeable
Length700mm
Number of poles5
Suitable for emergency lightingNo
Ball-proofNo
Reflector colourSilver
Nominal voltage220 - 240V
Light sharingAsymmetric
Material reflectorPlastic
Impact strengthIK08
ReflectorHigh-gloss
With light sourceYes
Emergency power supply integratedNo
Luminaire with limited surface temperature, sign "D“Yes
Suitable for number of lamps4
With control gearYes
With protective coverYes
Colour of lightWhite
Nominal current250 - 250mA
Rated luminous flux according to IEC 62722-2-127600lm
Beam angleWide beam 41-80°
Constant light output (CLO)No
Dimming 0-10 VNo
Type of wiringEnding
Colour consistency (McAdam ellipse)SDCM3
Rated ambient temperature according to IEC62722-2-1-30 - 50°C
Filament test according to IEC 60695-2-11850 °C - 30 s
Photobiological safety according to EN 62471RG0
Dimming DMXNo
Dimming potentiometer (integrated)No
Dimming LineSwitchNo
Dimming 1-10 VNo
Dimming DALIYes
Dimming phase cut-onNo
Dimming RFNo
Dimming programmableNo
Dimming phase cut-offNo
Dimming Sine Wave ReductionNo
Dimming mains voltage modulationNo
Dimming manufacturer's proprietary systemNo
No dim functionNo
Dimming ZigbeeNo
Dimming with push-buttonNo
Dimming DSINo
Dimming Touch and DimNo
Luminaire efficacy146lm/W
Light distributorRefractor lens
Suitable for auxiliary lampNo
Max. number of luminaires per miniature circuit breaker B167
Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq)90%
Max. number of luminaires per miniature circuit breaker C1611
Operation by BluetoothNo
Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq)10%
Beam angle adjustableNo
Colour temperature adjustableNo
Luminous flux adjustableContinuously variable
Power factor0.9
Exchangeable control gearYes
Degree of protection (IP)IP66
Colour temperature5700 - 5700K
Max. system power189W
