Details
- •Luminaires
- •High bay luminaire
- •1 KOM
- •GEWISS
Technical specifications
Protection classI
Lamp holderNone
Colour housingGrey
ReflectorHigh-gloss
Width504mm
Mounting methodPendant
Ball-proofYes
Voltage typeAC
Connection typePush-in clamp
Conductor cross section1.5mm²
Colour rendering index CRI80-89
Type of control gearLED operating device current-controlled
Number of poles3
Length700mm
Degree of protection (IP)IP66
Material reflectorPlastic
Light sharingSymmetric
With light sourceYes
Impact strengthIK08
Height/depth114mm
With protective coverYes
Material housingPlastic
Reflector colourSilver
Lamp typeLED not exchangeable
Constant light output (CLO)No
Beam angleExtreme wide beam >80°
Nominal voltage220 - 240V
Luminaire with limited surface temperature, sign "D“Yes
Emergency power supply integratedNo
Rated luminous flux according to IEC 62722-2-139600lm
Colour of lightWhite
Max. system power253W
With control gearYes
Suitable for emergency lightingNo
Suitable for number of lamps4
Colour temperature5700 - 5700K
Nominal current330 - 330mA
Type of wiringEnding
Dimming 1-10 VNo
Filament test according to IEC 60695-2-11850 °C - 30 s
Dimming mains voltage modulationNo
Dimming ZigbeeNo
Dimming Sine Wave ReductionNo
Dimming 0-10 VNo
Dimming DMXNo
Dimming manufacturer's proprietary systemNo
Rated ambient temperature according to IEC62722-2-1-30 - 50°C
Dimming DSINo
Dimming RFNo
Dimming phase cut-offNo
Colour consistency (McAdam ellipse)SDCM3
Dimming Touch and DimNo
Light distributorRefractor lens
Dimming DALINo
Dimming potentiometer (integrated)No
Luminaire efficacy157lm/W
Dimming programmableNo
Photobiological safety according to EN 62471RG0
Dimming with push-buttonNo
Dimming phase cut-onNo
No dim functionYes
Dimming LineSwitchNo
Max. number of luminaires per miniature circuit breaker C168
Luminous flux adjustableNo
Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq)90%
Colour temperature adjustableNo
Suitable for auxiliary lampNo
Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq)10%
Operation by BluetoothNo
Beam angle adjustableNo
Power factor0.9
Exchangeable control gearYes
Max. number of luminaires per miniature circuit breaker B164
