Technical specifications
Mounting methodPendant
Protection classI
Width376mm
ReflectorNone
Colour housingGrey
Type of control gearLED operating device current-controlled
Lamp holderNone
Ball-proofNo
Number of poles5
Length434mm
Conductor cross section1.5mm²
Colour rendering index CRI80-89
Suitable for emergency lightingNo
Connection typePush-in clamp
Material housingAluminium
Light sharingSymmetric
Lamp typeLED not exchangeable
Voltage typeAC
Material reflectorWithout reflector
With light sourceYes
With control gearYes
Emergency power supply integratedNo
Nominal voltage220 - 240V
Suitable for number of lamps6
Degree of protection (IP)IP65
Luminaire with limited surface temperature, sign "D“No
With protective coverNo
Height/depth171mm
Impact strengthIK07
Nominal current600 - 600mA
Max. system power125W
Type of wiringEnding
Colour temperature3000 - 3000K
Rated ambient temperature according to IEC62722-2-1-25 - 50°C
Dimming 0-10 VNo
Dimming DALIYes
Constant light output (CLO)No
Dimming DMXNo
Colour consistency (McAdam ellipse)SDCM3
Rated luminous flux according to IEC 62722-2-113400lm
Colour of lightWhite
Photobiological safety according to EN 62471RG0
Beam angleMedium beam 21-40°
Dimming 1-10 VNo
Dimming potentiometer (integrated)No
Filament test according to IEC 60695-2-11650 °C - 30 s
Dimming LineSwitchNo
Dimming programmableNo
Dimming manufacturer's proprietary systemNo
Dimming phase cut-offNo
Dimming Sine Wave ReductionNo
Dimming mains voltage modulationNo
Dimming RFNo
Dimming phase cut-onNo
No dim functionNo
Dimming DSINo
Light distributorFocal lens
Dimming with push-buttonNo
Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq)10%
Suitable for auxiliary lampNo
Luminous flux adjustableContinuously variable
Dimming ZigbeeNo
Operation by BluetoothNo
Colour temperature adjustableNo
Max. number of luminaires per miniature circuit breaker B168
Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq)90%
Luminaire efficacy107lm/W
Max. number of luminaires per miniature circuit breaker C1613
Dimming Touch and DimNo
Exchangeable control gearYes
Beam angle adjustableNo
Power factor0.9
