Details
- •Luminaires
- •High bay luminaire
- •1 KOM
- •GEWISS
Technical specifications
Colour housingGrey
ReflectorNone
Colour rendering index CRI80-89
Connection typePush-in clamp
Mounting methodPendant
Number of poles5
Conductor cross section1.5mm²
Type of control gearLED operating device current-controlled
Protection classI
Voltage typeAC
Height/depth176mm
Length539mm
Lamp holderNone
Material housingAluminium
Width477mm
Ball-proofNo
Lamp typeLED not exchangeable
Suitable for emergency lightingNo
Impact strengthIK07
Light sharingSymmetric/asymmetric
Material reflectorWithout reflector
With control gearYes
Suitable for number of lamps6
Colour of lightWhite
Luminaire with limited surface temperature, sign "D“No
With light sourceYes
Nominal current900 - 900mA
Emergency power supply integratedNo
Rated luminous flux according to IEC 62722-2-124100lm
Beam angleWide beam 41-80°
Nominal voltage220 - 240V
With protective coverYes
Dimming 0-10 VNo
Filament test according to IEC 60695-2-11650 °C - 30 s
Type of wiringEnding
Constant light output (CLO)No
Rated ambient temperature according to IEC62722-2-1-25 - 50°C
Photobiological safety according to EN 62471RG0
Colour consistency (McAdam ellipse)SDCM3
Dimming 1-10 VNo
Dimming DMXNo
Dimming phase cut-onNo
Dimming mains voltage modulationNo
Dimming potentiometer (integrated)No
Dimming manufacturer's proprietary systemNo
Dimming DALIYes
Dimming with push-buttonNo
Dimming Sine Wave ReductionNo
Light distributorFocal lens
No dim functionNo
Dimming phase cut-offNo
Dimming ZigbeeNo
Dimming DSINo
Dimming RFNo
Luminaire efficacy115lm/W
Dimming Touch and DimNo
Dimming programmableNo
Dimming LineSwitchNo
Luminous flux adjustableContinuously variable
Operation by BluetoothNo
Max. number of luminaires per miniature circuit breaker C162
Colour temperature adjustableNo
Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq)90%
Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq)10%
Suitable for auxiliary lampNo
Power factor0.9
Exchangeable control gearYes
Beam angle adjustableNo
Degree of protection (IP)IP65
Colour temperature5700 - 5700K
Max. system power210W
