Details
- •Luminaires
- •Luminaire for streets and places
- •1 KOM
- •GEWISS
Technical specifications
Mounting methodPost top
Colour of lightWhite
Colour temperature4000 - 4000K
With light sourceYes
Lamp typeLED not exchangeable
Suitable for number of lamps4
Lamp holderNone
Material housingAluminium
Surface protectionPowder coating
Material coverGlass structured
Colour housingGrey
Nominal voltage220 - 240V
Voltage typeAC
Nominal current1000 - 1000mA
Type of control gearLED operating device current-controlled
With control gearYes
Exchangeable control gearYes
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DMXNo
Dimming LineSwitchNo
Dimming DSINo
Dimming potentiometer (integrated)No
Dimming manufacturer's proprietary systemNo
Dimming DALIYes
Dimming mains voltage modulationNo
Dimming phase cut-offNo
Dimming phase cut-onNo
Dimming programmableNo
Dimming RFNo
Dimming Touch and DimNo
Colour rendering index CRI70-79
Power factor0.9
Width330mm
Height/depth215mm
Length690mm
Type of wiringEnding
Number of poles2
Compatible with Apple HomeKitNo
Conductor cross section2.5mm²
Compatible with Google AssistantNo
Connection typeScrewed terminal
IFTTT support availableNo
Compatible with Amazon AlexaNo
Operation by BluetoothNo
Type of connection for sensor/communication moduleOther
With light sensorNo
Dimming with push-buttonNo
Light distributorReflector
Adjustable opticsNo
Colour consistency (McAdam ellipse)SDCM5
Impact strengthIK08
Rated ambient temperature according to IEC62722-2-1-25 - 40°C
Protection classII
Suitable for spigot size42 - 76mm
Remote controlNone
Luminaire with limited surface temperature, sign "D“No
With radio controlNo
Rated luminous flux according to IEC 62722-2-119700lm
With connection cableNo
Constant light output (CLO)No
Dimming Sine Wave ReductionNo
Dimming ZigbeeNo
No dim functionNo
Degree of protection (IP)IP66
Luminaire efficacy133lm/W
With light regulation program controlYes
Max. system power148W
