Details
- •Luminaires
- •Luminaire for streets and places
- •1 KOM
- •GEWISS
Technical specifications
Mounting methodPost top
Colour of lightWhite
Colour temperature4000 - 4000K
With light sourceYes
Lamp typeLED not exchangeable
Lamp holderNone
Suitable for number of lamps5
Material housingAluminium
Surface protectionPowder coating
Material coverGlass structured
Voltage typeAC
Colour housingGrey
With control gearYes
Exchangeable control gearYes
Nominal voltage220 - 240V
Type of control gearLED operating device current-controlled
Dimming DALIYes
Nominal current700 - 700mA
Dimming DMXNo
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming potentiometer (integrated)No
Dimming LineSwitchNo
Dimming manufacturer's proprietary systemNo
Dimming DSINo
Dimming mains voltage modulationNo
Dimming programmableNo
Dimming phase cut-offNo
Dimming phase cut-onNo
Dimming Touch and DimNo
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming ZigbeeNo
Dimming with push-buttonNo
No dim functionNo
Light distributorReflector
Colour rendering index CRI70-79
Width330mm
Power factor0.9
Height/depth215mm
Length690mm
Type of wiringEnding
Number of poles2
Conductor cross section2.5mm²
Compatible with Apple HomeKitNo
Compatible with Google AssistantNo
Connection typeScrewed terminal
Compatible with Amazon AlexaNo
IFTTT support availableNo
Operation by BluetoothNo
Type of connection for sensor/communication moduleOther
With light sensorNo
Impact strengthIK08
Adjustable opticsNo
Protection classII
With light regulation program controlYes
With connection cableNo
Rated ambient temperature according to IEC62722-2-1-25 - 40°C
Luminaire with limited surface temperature, sign "D“No
Suitable for spigot size42 - 76mm
With radio controlNo
Degree of protection (IP)IP66
Luminaire efficacy144lm/W
Remote controlNone
Rated luminous flux according to IEC 62722-2-118300lm
Constant light output (CLO)No
Colour consistency (McAdam ellipse)SDCM5
Max. system power127W
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
GWR5275V | Road 5 MED.V.AL.5M 4000K 700MA Opt.w
