GWR5275V | Road 5 MED.V.AL.5M 4000K 700MA Opt.w
Code: 1977855
ManufacturerGewiss
Catalog numberGWR5275V
TypeLuminaire for streets and places
CategoryLuminaire for streets and places
EAN code8011564883222
Details
- •ROAD5 MEDI V.WIDE 5M 4000K 0,7A CL2
- •Luminaires
- •Luminaire for streets and places
- •Minimum order quantity: 1 pcs
- •GEWISS
Technical specifications
Colour of lightWhite
Colour temperature4000 - 4000K
With light sourceYes
Lamp holderNone
Suitable for number of lamps5
Material housingAluminium
Surface protectionPowder coating
Material coverGlass structured
Voltage typeAC
With control gearYes
Exchangeable control gearYes
Type of control gearLED operating device current-controlled
Dimming DALIYes
Nominal current700 - 700mA
Dimming DMXNo
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming potentiometer (integrated)No
Dimming LineSwitchNo
Dimming manufacturer's proprietary systemNo
Dimming DSINo
Dimming mains voltage modulationNo
Dimming programmableNo
Dimming phase cut-offNo
Dimming phase cut-onNo
Dimming Touch and DimNo
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming ZigbeeNo
Dimming with push-buttonNo
No dim functionNo
Light distributorReflector
Colour rendering index CRI70-79
Width330mm
Power factor0.9
Height/depth215mm
Length690mm
Type of wiringEnding
Number of poles2
Conductor cross section2.5mm²
Compatible with Apple HomeKitNo
Compatible with Google AssistantNo
Connection typeScrewed terminal
Compatible with Amazon AlexaNo
IFTTT support availableNo
Operation by BluetoothNo
Type of connection for sensor/communication moduleOther
With light sensorNo
Impact strengthIK08
Adjustable opticsNo
Protection classII
With light regulation program controlYes
With connection cableNo
Rated ambient temperature according to IEC62722-2-1-25 - 40°C
Luminaire with limited surface temperature, sign "D“No
Suitable for spigot size42 - 76mm
With radio controlNo
Luminaire efficacy144lm/W
Remote controlNone
Rated luminous flux according to IEC 62722-2-118300lm
Constant light output (CLO)No
Colour consistency (McAdam ellipse)SDCM5
Max. system power127W
Mounting methodPost top
Colour housingGrey
Lamp typeLED not exchangeable
Nominal voltage220 - 240V
Degree of protection (IP)IP66
