PL-LIN-Z6 2200-840 560X20-LV
Code: 1979468
Details
- •Lamps
- •LED-module
- •1 KOM
- •LEDVANCE
Technical specifications
Suitable for constant currentYes
Suitable for constant voltageNo
Voltage typeDC
Lamp power11.80 - 11.80W
ShapeRectangular
Lamp voltage23.6 - 23.6V
Number of LEDs72
External driver requiredYes
Colour of light according to EN 12464-1Neutral white 3300-5300 K
Colour temperature4000K
Beam angle120.00 - 120.00°
Luminous intensity735cd
Suitable for rail trafficNo
Width20.00mm
Luminous flux2267 - 2267lm
Length560.00mm
Suitable for variable road signsNo
Compatible with Google AssistantNo
Photobiological safety according to EN 62471RG1
Energy efficiency classC
IFTTT support availableYes
Degree of protection (IP)IP20
Colour consistency (McAdam ellipse)SDCM3
Suitable for traffic lightsNo
Suitable for matrix information boardsNo
Height5.00mm
Compatible with Apple HomeKitNo
Average nominal lifespan50000h
Compatible with Amazon AlexaNo
Suitable for general lightingYes
FlexibleNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PL-LIN-Z6 2200-840 560X20-LV
Details
- Lamps
- LED-module
- 1 KOM
- LEDVANCE
DetailsTechnical specifications
Technical specifications
Suitable for constant current
Suitable for constant voltage
Voltage type
DC
Lamp power
11.80 .. 11.80W
Shape
Rectangular
Lamp voltage
23.6 .. 23.6V
Number of LEDs
72
External driver required
Colour of light according to EN 12464-1
Neutral white 3300-5300 K
Colour temperature
4000K
Beam angle
120.00 .. 120.00°
Luminous intensity
735cd
Suitable for rail traffic
Width
20.00mm
Luminous flux
2267 .. 2267lm
Length
560.00mm
Suitable for variable road signs
Compatible with Google Assistant
Photobiological safety according to EN 62471
RG1
Energy efficiency class
C
IFTTT support available
Degree of protection (IP)
IP20
Colour consistency (McAdam ellipse)
SDCM3
Suitable for traffic lights
Suitable for matrix information boards
Height
5.00mm
Compatible with Apple HomeKit
Average nominal lifespan
50000h
Compatible with Amazon Alexa
Suitable for general lighting
Flexible
