Details
- •Low-voltage industrial components
- •Contactor relay
- •1 KOM
- •ABB
Technical specifications
Height48mm
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally open contact3
Rated control supply voltage Us at AC 60HZ- - -V
Mounting methodDIN rail
Voltage type (operating voltage)DC
Suitable for manual operationNo
Depth68mm
Rated operation current Ie, 400 V4A
Rated control supply voltage Us at AC 50HZ- - -V
With LED indicationNo
Number of auxiliary contacts as normally closed contact1
InterfaceNo
Width45mm
Rated control supply voltage Us at DC77 - 137V
Connection type auxiliary circuitScrew connection
Rated switch current6A
Number of auxiliary contacts as normally closed contact, delayed switching0
Voltage type for actuatingDC
Operating voltage at DC440 - 440V
Operating voltage at AC 50 Hz690 - 690V
Operating voltage at AC 60 Hz690 - 690V
Number of auxiliary contacts as normally open contact, leading0
Rated operation current6A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SAH102569R9910 | MCRC031ATWJD-RAIL
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Contactor relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Height
48mm
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally open contact
3
Rated control supply voltage Us at AC 60HZ
- .. -V
Mounting method
DIN rail
Voltage type (operating voltage)
DC
Suitable for manual operation
Depth
68mm
Rated operation current Ie, 400 V
4A
Rated control supply voltage Us at AC 50HZ
- .. -V
With LED indication
Number of auxiliary contacts as normally closed contact
1
Interface
Width
45mm
Rated control supply voltage Us at DC
77 .. 137V
Connection type auxiliary circuit
Screw connection
Rated switch current
6A
Number of auxiliary contacts as normally closed contact, delayed switching
0
Voltage type for actuating
DC
Operating voltage at DC
440 .. 440V
Operating voltage at AC 50 Hz
690 .. 690V
Operating voltage at AC 60 Hz
690 .. 690V
Number of auxiliary contacts as normally open contact, leading
0
Rated operation current
6A
