Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Number of poles4
Width212.5mm
Number of auxiliary contacts as normally open contact0
Rated operating voltage1000 - 1000V
Number of switches1
Depth82.5mm
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu200A
Rated operation power at AC-3, 400 V-kW
InterlockableNo
Degree of protection (IP), front sideIP00
Number of auxiliary contacts as change-over contact0
Height170mm
Motor drive integratedNo
Conditioned rated short-circuit current Iq-kA
Width in number of modular spacings-
Rated short-time withstand current lcw8kA
Rated operation power at AC-23, 400 V110kW
Version as safety switchNo
Version as main switchYes
Type of control elementLong turning handle
Version as maintenance-/service switchYes
Type of electrical connection of main circuitBolt connection
Version as emergency stop installationNo
Suitable for floor mountingNo
Device constructionComplete device in housing
Motor drive optionalNo
Voltage release optionalNo
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Suitable for front mounting centreNo
Rated permanent current at AC-23, 400 V250A
Suitable for front mounting 4-holeNo
Switching power at 400 V110kW
Degree of protection (NEMA)Other
Version as reversing switchNo
Rated permanent current at AC-21, 400 V-A
Max. rated operation voltage Ue AC1000V
With pre-assembled cablingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022723R0490 | OT200U04
