1SCA022749R3740 | OT200U02P
Code: 1981685
ManufacturerABB
Catalog number1SCA022749R3740
TypeSwitch disconnector (low voltage)
CategorySwitch disconnector
EAN code6417019243320
Details
- •OT200U02P SWITCH-DISCONNECTOR
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Depth82.5mm
Width126.5mm
Rated operation power at AC-3, 400 V-kW
Height170mm
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Width in number of modular spacings-
Conditioned rated short-circuit current Iq-kA
Version as main switchYes
InterlockableNo
Rated operating voltage1000 - 1000V
Version as safety switchNo
Suitable for front mounting 4-holeNo
Number of auxiliary contacts as change-over contact0
Number of switches1
Suitable for front mounting centreNo
Degree of protection (IP), front sideIP00
Rated short-time withstand current lcw8kA
Suitable for distribution board installationYes
Type of electrical connection of main circuitBolt connection
Colour control elementBlack
Rated operation power at AC-23, 400 V-kW
Type of control elementLong turning handle
Suitable for floor mountingNo
Version as emergency stop installationNo
Motor drive integratedNo
Version as maintenance-/service switchYes
Voltage release optionalNo
Suitable for intermediate mountingNo
Motor drive optionalNo
Rated permanent current at AC-21, 400 V-A
Switching power at 400 V-kW
Device constructionComplete device in housing
Rated permanent current at AC-23, 400 V-A
Version as reversing switchNo
Degree of protection (NEMA)Other
With pre-assembled cablingNo
Rated permanent current Iu200A
Number of poles2
Max. rated operation voltage Ue AC1000V
