Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Depth105mm
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Number of poles3
Rated permanent current Iu400A
Width in number of modular spacings-
Height220mm
Width226mm
Type of electrical connection of main circuitBolt connection
Version as emergency stop installationNo
Conditioned rated short-circuit current Iq-kA
Number of switches1
Rated operating voltage1000 - 1000V
InterlockableNo
Degree of protection (IP), front sideIP00
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally open contact0
Motor drive integratedNo
Version as safety switchNo
Type of control elementOther
Version as main switchYes
Suitable for front mounting 4-holeNo
Rated short-time withstand current lcw15kA
Rated operation power at AC-23, 400 V220kW
Suitable for floor mountingNo
Degree of protection (NEMA)Other
Voltage release optionalNo
Suitable for distribution board installationYes
With pre-assembled cablingNo
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC1000V
Switching power at 400 V220kW
Rated permanent current at AC-23, 400 V400A
Version as maintenance-/service switchYes
Device constructionComplete device in housing
Rated permanent current at AC-21, 400 V-A
Motor drive optionalNo
Suitable for front mounting centreNo
Version as reversing switchNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022762R6300 | OT400U21
