Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq-kA
Rated operation power at AC-3, 400 V-kW
Rated permanent current Iu600A
Number of auxiliary contacts as normally open contact0
Depth140mm
Width in number of modular spacings-
Number of auxiliary contacts as normally closed contact0
Number of poles3
Height250mm
Rated operating voltage1000 - 1000V
Width266mm
Degree of protection (IP), front sideIP00
Rated short-time withstand current lcw20kA
InterlockableNo
Version as safety switchNo
Number of auxiliary contacts as change-over contact0
Voltage release optionalNo
Switching power at 400 V450kW
Suitable for intermediate mountingNo
Rated operation power at AC-23, 400 V450kW
Motor drive integratedNo
Suitable for front mounting 4-holeNo
Version as maintenance-/service switchYes
Suitable for front mounting centreNo
Device constructionComplete device in housing
Version as main switchYes
Suitable for floor mountingNo
Max. rated operation voltage Ue AC1000V
Number of switches1
Type of electrical connection of main circuitBolt connection
Version as reversing switchNo
Rated permanent current at AC-21, 400 V-A
Motor drive optionalNo
Type of control elementOther
Suitable for distribution board installationYes
Version as emergency stop installationNo
Rated permanent current at AC-23, 400 V800A
With pre-assembled cablingNo
Degree of protection (NEMA)Other
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022798R0730 | OT600U03
