1SCA022799R7200 | OT315E01
Code: 1981803
ManufacturerABB
Catalog number1SCA022799R7200
TypeSwitch disconnector (low voltage)
CategorySwitch disconnector
EAN code6417019264851
Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Width103mm
Depth107mm
Number of auxiliary contacts as normally open contact0
Height185mm
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact0
Conditioned rated short-circuit current Iq-kA
Rated operating voltage1000 - 1000V
Width in number of modular spacings-
Degree of protection (IP), front sideIP00
Version as emergency stop installationNo
Motor drive integratedNo
Number of switches1
Suitable for front mounting 4-holeNo
Type of electrical connection of main circuitBolt connection
Suitable for distribution board installationYes
Version as maintenance-/service switchYes
Suitable for front mounting centreNo
Rated short-time withstand current lcw15kA
Version as safety switchNo
InterlockableNo
Rated operation power at AC-23, 400 V180kW
Type of control elementOther
Version as main switchYes
Suitable for intermediate mountingNo
Motor drive optionalNo
Suitable for floor mountingNo
Rated permanent current at AC-23, 400 V315A
Switching power at 400 V180kW
Rated permanent current at AC-21, 400 V315A
Device constructionComplete device in housing
Voltage release optionalNo
Version as reversing switchNo
Degree of protection (NEMA)Other
With pre-assembled cablingNo
Rated permanent current Iu315A
Number of poles1
Max. rated operation voltage Ue AC1000V
