Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Version as reversing switchNo
Max. rated operation voltage Ue AC1000V
Number of switches1
Version as maintenance-/service switchYes
Version as main switchYes
Version as safety switchNo
Rated operation power at AC-3, 400 V-kW
Switching power at 400 V355kW
Rated permanent current Iu630A
Rated permanent current at AC-21, 400 V630A
Rated permanent current at AC-23, 400 V630A
Conditioned rated short-circuit current Iq-kA
Version as emergency stop installationNo
Rated operation power at AC-23, 400 V355kW
Rated short-time withstand current lcw20kA
Rated operating voltage1000 - 1000V
With pre-assembled cablingNo
Voltage release optionalNo
Device constructionComplete device in housing
InterlockableNo
Degree of protection (IP), front sideIP00
Suitable for front mounting 4-holeNo
Type of electrical connection of main circuitBolt connection
Degree of protection (NEMA)Other
Type of control elementOther
Width136mm
Number of auxiliary contacts as normally open contact0
Number of poles1
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Number of auxiliary contacts as change-over contact0
Suitable for floor mountingNo
Number of auxiliary contacts as normally closed contact0
Suitable for front mounting centreNo
Motor drive integratedNo
Motor drive optionalNo
Height250mm
Width in number of modular spacings-
Depth140mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022799R7460 | OT630E01
