Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Height250mm
Width331mm
Conditioned rated short-circuit current Iq-kA
Version as emergency stop installationNo
Depth140mm
Motor drive integratedNo
Rated operating voltage1000 - 1000V
Number of switches1
Type of electrical connection of main circuitBolt connection
Number of auxiliary contacts as change-over contact0
Number of poles4
Rated permanent current Iu600A
InterlockableNo
Degree of protection (IP), front sideIP00
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Width in number of modular spacings-
Version as safety switchNo
Type of control elementOther
Version as main switchYes
Rated short-time withstand current lcw20kA
Version as maintenance-/service switchYes
Suitable for front mounting 4-holeNo
Suitable for distribution board installationYes
Rated operation power at AC-23, 400 V450kW
Suitable for floor mountingNo
Suitable for intermediate mountingNo
Degree of protection (NEMA)Other
With pre-assembled cablingNo
Switching power at 400 V450kW
Device constructionComplete device in housing
Rated permanent current at AC-23, 400 V800A
Voltage release optionalNo
Motor drive optionalNo
Suitable for front mounting centreNo
Version as reversing switchNo
Rated permanent current at AC-21, 400 V-A
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022800R1910 | OT600U13
