Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Number of poles3
Width266mm
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Depth140mm
Height250mm
Rated permanent current Iu600A
Degree of protection (IP), front sideIP00
Conditioned rated short-circuit current Iq-kA
Type of electrical connection of main circuitBolt connection
Version as emergency stop installationNo
Number of auxiliary contacts as change-over contact0
Rated operating voltage1000 - 1000V
InterlockableNo
Number of switches1
Motor drive integratedNo
Width in number of modular spacings-
Suitable for front mounting 4-holeNo
Rated operation power at AC-23, 400 V450kW
Suitable for distribution board installationYes
Suitable for floor mountingNo
Version as maintenance-/service switchYes
Type of control elementOther
Version as safety switchNo
Rated short-time withstand current lcw20kA
Rated permanent current at AC-21, 400 V-A
Version as reversing switchNo
Switching power at 400 V450kW
Motor drive optionalNo
Max. rated operation voltage Ue AC1000V
Voltage release optionalNo
Suitable for front mounting centreNo
Device constructionComplete device in housing
Version as main switchYes
Degree of protection (NEMA)Other
With pre-assembled cablingNo
Rated permanent current at AC-23, 400 V800A
Suitable for intermediate mountingNo
