Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Height185mm
Width221mm
Depth107mm
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Degree of protection (IP), front sideIP00
Width in number of modular spacings-
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact0
Rated operating voltage1000 - 1000V
Type of electrical connection of main circuitBolt connection
InterlockableNo
Conditioned rated short-circuit current Iq-kA
Motor drive integratedNo
Number of switches1
Version as main switchYes
Version as maintenance-/service switchYes
Version as emergency stop installationNo
Suitable for floor mountingNo
Suitable for front mounting centreNo
Rated operation power at AC-23, 400 V180kW
Rated short-time withstand current lcw15kA
Suitable for front mounting 4-holeNo
Version as safety switchNo
Type of control elementOther
Suitable for intermediate mountingNo
Suitable for distribution board installationYes
Motor drive optionalNo
Version as reversing switchNo
With pre-assembled cablingNo
Switching power at 400 V180kW
Rated permanent current at AC-21, 400 V315A
Device constructionComplete device in housing
Rated permanent current at AC-23, 400 V315A
Degree of protection (NEMA)Other
Voltage release optionalNo
Rated permanent current Iu315A
Number of poles3
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022809R8570 | OT315E03W
