Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally open contact0
Height185mm
Rated operation power at AC-3, 400 V-kW
Width275mm
Depth107mm
Rated permanent current Iu315A
Width in number of modular spacings-
Rated operation power at AC-23, 400 V180kW
Version as main switchYes
Type of electrical connection of main circuitBolt connection
Suitable for front mounting 4-holeNo
Rated operating voltage1000 - 1000V
InterlockableNo
Suitable for front mounting centreNo
Degree of protection (IP), front sideIP00
Version as emergency stop installationNo
Motor drive integratedNo
Number of auxiliary contacts as normally closed contact0
Type of control elementOther
Rated short-time withstand current lcw15kA
Number of switches1
Conditioned rated short-circuit current Iq-kA
Version as safety switchNo
Number of poles4
Number of auxiliary contacts as change-over contact0
Version as maintenance-/service switchYes
Suitable for distribution board installationYes
Suitable for floor mountingNo
Suitable for intermediate mountingNo
Version as reversing switchNo
Degree of protection (NEMA)Other
With pre-assembled cablingNo
Rated permanent current at AC-21, 400 V315A
Rated permanent current at AC-23, 400 V315A
Max. rated operation voltage Ue AC1000V
Switching power at 400 V180kW
Device constructionComplete device in housing
Motor drive optionalNo
Voltage release optionalNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA022809R9030 | OT315E04W
