1SCA022811R2820 | OS400D02
Code: 1981816
ManufacturerABB
Catalog number1SCA022811R2820
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019273594
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Motor drive integratedNo
Version as safety switchYes
Version as emergency stop installationNo
Suitable for front mountingNo
Type of control elementShort thumb-grip
Rated short-time withstand current lcw14kA
Suitable for floor mountingNo
Rated operation power at AC-23, 400 V400kW
Version as main switchYes
Conditioned rated short-circuit current Iq80kA
Cable entryOther
Type of electrical connection of main circuitBolt connection
With error protectionNo
Suitable for busbar mountingYes
Motor drive optionalNo
Equipped with connectorsYes
Position control elementLeft
Rated permanent current Iu400A
Number of poles2
Suitable for fusesNH0
Max. rated operation voltage Ue AC1000V
