Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Rated permanent current Iu250A
Version as emergency stop installationNo
Type of control elementLong turning handle
Suitable for fusesNH0
Motor drive integratedNo
Version as safety switchYes
Number of poles2
Rated short-time withstand current lcw8kA
Version as main switchYes
Rated operation power at AC-23, 400 V250kW
Type of electrical connection of main circuitBolt connection
Conditioned rated short-circuit current Iq80kA
Position control elementLeft
Max. rated operation voltage Ue AC1000V
Suitable for floor mountingNo
Suitable for busbar mountingYes
Motor drive optionalNo
With error protectionNo
Suitable for front mountingNo
Equipped with connectorsYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA101367R1001 | OS250D02K
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Cable entry
Other
Rated permanent current Iu
250A
Version as emergency stop installation
Type of control element
Long turning handle
Suitable for fuses
NH0
Motor drive integrated
Version as safety switch
Number of poles
2
Rated short-time withstand current lcw
8kA
Version as main switch
Rated operation power at AC-23, 400 V
250kW
Type of electrical connection of main circuit
Bolt connection
Conditioned rated short-circuit current Iq
80kA
Position control element
Left
Max. rated operation voltage Ue AC
1000V
Suitable for floor mounting
Suitable for busbar mounting
Motor drive optional
With error protection
Suitable for front mounting
Equipped with connectors
