Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Conditioned rated short-circuit current Iq80kA
Type of electrical connection of main circuitBolt connection
Type of control elementShort thumb-grip
Version as safety switchYes
Motor drive integratedNo
Version as emergency stop installationNo
Rated operation power at AC-23, 400 V250kW
Version as main switchYes
With error protectionNo
Suitable for busbar mountingYes
Motor drive optionalNo
Position control elementFront side
Equipped with connectorsYes
Suitable for front mountingNo
Suitable for floor mountingNo
Rated short-time withstand current lcw8kA
Rated permanent current Iu250A
Number of poles3
Suitable for fusesNH0
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA102202R1001 | OS250D12BB
