Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Depth167mm
Rated operation power at AC-3, 400 V-kW
Conditioned rated short-circuit current Iq-kA
Width in number of modular spacings-
Number of poles4
Width414.5mm
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu1600A
Degree of protection (IP), front sideIP00
Rated operating voltage1000 - 1000V
Number of auxiliary contacts as normally open contact0
Height372mm
Number of auxiliary contacts as change-over contact0
Version as emergency stop installationNo
Type of control elementLong turning handle
Number of switches1
Type of electrical connection of main circuitBolt connection
Motor drive integratedNo
Version as main switchYes
InterlockableNo
Rated permanent current at AC-23, 400 V1250A
Suitable for distribution board installationNo
Suitable for front mounting centreNo
Device constructionComplete device in housing
Degree of protection (NEMA)Other
Rated permanent current at AC-21, 400 V1600A
Suitable for floor mountingNo
Rated short-time withstand current lcw50kA
Rated operation power at AC-23, 400 V710kW
Voltage release optionalNo
Colour control elementBlack
Switching power at 400 V710kW
Version as maintenance-/service switchYes
Suitable for front mounting 4-holeNo
Version as reversing switchNo
Max. rated operation voltage Ue AC1000V
With pre-assembled cablingNo
Suitable for intermediate mountingNo
Motor drive optionalNo
Version as safety switchNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA102836R1001 | OT1600E13P
