Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu-A
Depth335mm
Height376mm
Width in number of modular spacings-
Number of poles4
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as change-over contact0
Width480mm
Degree of protection (IP), front sideIP20
Conditioned rated short-circuit current Iq-kA
Rated operating voltage1000 - 1000V
Number of switches1
Version as main switchYes
InterlockableYes
Suitable for distribution board installationYes
Rated operation power at AC-23, 400 V-kW
Version as maintenance-/service switchYes
Colour control elementBlack
Rated permanent current at AC-23, 400 V1600A
Max. rated operation voltage Ue AC1000V
Motor drive integratedNo
Suitable for front mounting centreNo
Version as safety switchNo
Voltage release optionalNo
Suitable for floor mountingNo
Motor drive optionalNo
Suitable for intermediate mountingNo
Rated short-time withstand current lcw50kA
Type of control elementOther
Type of electrical connection of main circuitScrew connection
Version as emergency stop installationNo
Version as reversing switchNo
Device constructionBuilt-in device plug-in technique
Switching power at 400 V-kW
Rated permanent current at AC-21, 400 V1600A
Suitable for front mounting 4-holeYes
Degree of protection (NEMA)1
With pre-assembled cablingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA104034R1001 | OT800U04C
