Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Width48mm
Depth56mm
Height68mm
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Number of poles4
Number of auxiliary contacts as change-over contact0
Rated operating voltage750 - 750V
Conditioned rated short-circuit current Iq-kA
Width in number of modular spacings-
Number of auxiliary contacts as normally closed contact0
Degree of protection (IP), front sideIP20
Rated permanent current Iu25A
Version as main switchYes
Type of electrical connection of main circuitScrew connection
Version as emergency stop installationNo
Number of switches1
Type of control elementOther
Motor drive integratedNo
Rated operation power at AC-23, 400 V7.5kW
Version as safety switchNo
InterlockableNo
Version as maintenance-/service switchYes
Suitable for front mounting 4-holeNo
Suitable for floor mountingNo
Rated short-time withstand current lcw0.5kA
Suitable for distribution board installationYes
Suitable for front mounting centreNo
Suitable for intermediate mountingNo
Motor drive optionalNo
Max. rated operation voltage Ue AC750V
Voltage release optionalNo
Device constructionComplete device in housing
Rated permanent current at AC-21, 400 V16A
Version as reversing switchNo
Switching power at 400 V7.5kW
Rated permanent current at AC-23, 400 V16A
With pre-assembled cablingNo
Degree of protection (NEMA)Other
