Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Number of switches1
Rated permanent current Iu-A
Number of poles3
Rated operating voltage750 - 750V
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP20
Conditioned rated short-circuit current Iq-kA
Rated short-time withstand current lcw1kA
Type of control elementNone
Suitable for distribution board installationYes
Colour control elementBlack
Suitable for front mounting centreNo
Suitable for floor mountingNo
Type of electrical connection of main circuitScrew connection
Motor drive integratedNo
Version as emergency stop installationNo
Suitable for intermediate mountingNo
Version as main switchYes
Motor drive optionalNo
Rated permanent current at AC-21, 400 V63A
Version as reversing switchNo
Degree of protection (NEMA)1
Switching power at 400 V-kW
Suitable for front mounting 4-holeYes
Version as safety switchNo
Rated operation power at AC-23, 400 V-kW
Device constructionBuilt-in device plug-in technique
Rated permanent current at AC-23, 400 V45A
Voltage release optionalNo
Max. rated operation voltage Ue AC750V
Version as maintenance-/service switchYes
InterlockableYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA105078R1001 | OT60F3C
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Number of auxiliary contacts as normally closed contact
0
Rated operation power at AC-3, 400 V
-kW
Number of auxiliary contacts as normally open contact
0
Number of switches
1
Rated permanent current Iu
-A
Number of poles
3
Rated operating voltage
750 .. 750V
Number of auxiliary contacts as change-over contact
0
Degree of protection (IP), front side
IP20
Conditioned rated short-circuit current Iq
-kA
Rated short-time withstand current lcw
1kA
Type of control element
None
Suitable for distribution board installation
Colour control element
Black
Suitable for front mounting centre
Suitable for floor mounting
Type of electrical connection of main circuit
Screw connection
Motor drive integrated
Version as emergency stop installation
Suitable for intermediate mounting
Version as main switch
Motor drive optional
Rated permanent current at AC-21, 400 V
63A
Version as reversing switch
Degree of protection (NEMA)
1
Switching power at 400 V
-kW
Suitable for front mounting 4-hole
Version as safety switch
Rated operation power at AC-23, 400 V
-kW
Device construction
Built-in device plug-in technique
Rated permanent current at AC-23, 400 V
45A
Voltage release optional
Max. rated operation voltage Ue AC
750V
Version as maintenance-/service switch
Interlockable
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
