Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Width70mm
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Height72mm
Rated operating voltage750 - 750V
Number of auxiliary contacts as normally closed contact0
Depth69mm
Width in number of modular spacings-
Degree of protection (IP), front sideIP20
Conditioned rated short-circuit current Iq-kA
Type of electrical connection of main circuitScrew connection
Version as emergency stop installationNo
Number of switches1
Number of auxiliary contacts as change-over contact0
Version as maintenance-/service switchYes
Version as main switchYes
Version as safety switchNo
InterlockableNo
Type of control elementOther
Motor drive integratedNo
Suitable for front mounting 4-holeNo
Motor drive optionalNo
Suitable for distribution board installationYes
Version as reversing switchNo
Switching power at 400 V37kW
Suitable for floor mountingNo
Rated operation power at AC-23, 400 V37kW
Rated permanent current at AC-21, 400 V80A
Voltage release optionalNo
Suitable for front mounting centreNo
Device constructionComplete device in housing
Suitable for intermediate mountingNo
Rated short-time withstand current lcw1.5kA
Rated permanent current at AC-23, 400 V75A
With pre-assembled cablingNo
Degree of protection (NEMA)Other
Rated permanent current Iu80A
Number of poles4
Max. rated operation voltage Ue AC750V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA105500R1001 | OT80FT4N1
