1SCA105637R1001 | OT800U12
Code: 1982041
ManufacturerABB
Catalog number1SCA105637R1001
TypeSwitch disconnector (low voltage)
CategorySwitch disconnector
EAN code6417019395708
Details
- •OT800U12 SWITCH-DISCONNECTOR
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Width334.5mm
Height372mm
Depth151.5mm
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as change-over contact0
Width in number of modular spacings-
InterlockableNo
Conditioned rated short-circuit current Iq-kA
Degree of protection (IP), front sideIP00
Rated operating voltage1000 - 1000V
Type of control elementOther
Rated operation power at AC-23, 400 V710kW
Version as maintenance-/service switchYes
Suitable for distribution board installationYes
Rated short-time withstand current lcw50kA
Version as main switchYes
Suitable for front mounting centreNo
Number of switches1
Motor drive integratedNo
Suitable for floor mountingNo
Suitable for front mounting 4-holeNo
Type of electrical connection of main circuitBolt connection
Version as emergency stop installationNo
Version as safety switchNo
Motor drive optionalNo
Suitable for intermediate mountingNo
Rated permanent current at AC-21, 400 V-A
Device constructionComplete device in housing
Voltage release optionalNo
Version as reversing switchNo
Switching power at 400 V710kW
With pre-assembled cablingNo
Rated permanent current at AC-23, 400 V1250A
Degree of protection (NEMA)Other
Rated permanent current Iu800A
Number of poles3
Max. rated operation voltage Ue AC1000V
