1SCA108521R1001 | OT200E03CL
Code: 1982122
ManufacturerABB
Catalog number1SCA108521R1001
TypeSwitch disconnector (low voltage)
CategorySwitch disconnector
EAN code6417019397078
Details
- •OT200E03CL CHANGE-OVER SWITCH
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Height150mm
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Conditioned rated short-circuit current Iq-kA
Rated operating voltage1000 - 1000V
Depth160mm
Width in number of modular spacings-
Rated operation power at AC-3, 400 V-kW
Width170mm
InterlockableYes
Type of electrical connection of main circuitScrew connection
Number of auxiliary contacts as change-over contact0
Degree of protection (IP), front sideIP20
Motor drive integratedNo
Number of switches1
Version as safety switchNo
Rated operation power at AC-23, 400 V110kW
Type of control elementOther
Rated short-time withstand current lcw8kA
Version as maintenance-/service switchYes
Voltage release optionalNo
Suitable for front mounting 4-holeYes
Suitable for floor mountingNo
Suitable for front mounting centreNo
Colour control elementBlack
Suitable for intermediate mountingNo
Motor drive optionalNo
Suitable for distribution board installationYes
Version as reversing switchNo
Device constructionBuilt-in device plug-in technique
With pre-assembled cablingNo
Switching power at 400 V110kW
Rated permanent current at AC-21, 400 V200A
Degree of protection (NEMA)1
Version as emergency stop installationNo
Rated permanent current at AC-23, 400 V200A
Version as main switchYes
Rated permanent current Iu-A
Number of poles3
Max. rated operation voltage Ue AC1000V
