1SCA115199R1001 | OS32GD12
Code: 1982241
ManufacturerABB
Catalog number1SCA115199R1001
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019476391
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Conditioned rated short-circuit current Iq80kA
Type of control elementShort thumb-grip
Version as emergency stop installationNo
Motor drive integratedNo
Type of electrical connection of main circuitScrew connection
Version as safety switchYes
Rated operation power at AC-23, 400 V22kW
Suitable for front mountingNo
With error protectionNo
Version as main switchYes
Suitable for busbar mountingYes
Suitable for floor mountingNo
Equipped with connectorsYes
Motor drive optionalNo
Position control elementFront side
Rated short-time withstand current lcw2.5kA
Rated permanent current Iu32A
Number of poles3
Suitable for fusesNH000
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA115199R1001 | OS32GD12
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Cable entry
Other
Conditioned rated short-circuit current Iq
80kA
Type of control element
Short thumb-grip
Version as emergency stop installation
Motor drive integrated
Type of electrical connection of main circuit
Screw connection
Version as safety switch
Rated operation power at AC-23, 400 V
22kW
Suitable for front mounting
With error protection
Version as main switch
Suitable for busbar mounting
Suitable for floor mounting
Equipped with connectors
Motor drive optional
Position control element
Front side
Rated short-time withstand current lcw
2.5kA
Rated permanent current Iu
32A
Number of poles
3
Suitable for fuses
NH000
Max. rated operation voltage Ue AC
1000V
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
