1SCA115568R1001 | OS63GD04N1P
Code: 1982260
ManufacturerABB
Catalog number1SCA115568R1001
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019478883
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq80kA
Motor drive integratedNo
Version as safety switchYes
Cable entryOther
Type of control elementLong turning handle
Version as emergency stop installationNo
Version as main switchYes
Rated short-time withstand current lcw2.5kA
Position control elementLeft
Suitable for busbar mountingYes
Rated operation power at AC-23, 400 V55kW
Motor drive optionalNo
Suitable for floor mountingNo
Suitable for front mountingNo
With error protectionNo
Type of electrical connection of main circuitScrew connection
Equipped with connectorsYes
Rated permanent current Iu63A
Number of poles4
Suitable for fusesNH000
Max. rated operation voltage Ue AC1000V
