1SCA115928R1001 | OS160GBS40N1K
Code: 1982294
ManufacturerABB
Catalog number1SCA115928R1001
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019479286
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Conditioned rated short-circuit current Iq80kA
Cable entryOther
Type of electrical connection of main circuitBolt connection
Type of control elementLong turning handle
Version as safety switchYes
Version as emergency stop installationNo
Version as main switchYes
Motor drive integratedNo
Rated operation power at AC-23, 400 V132kW
Equipped with connectorsYes
Suitable for front mountingNo
Position control elementRight
Suitable for busbar mountingYes
Rated short-time withstand current lcw5kA
With error protectionNo
Suitable for floor mountingNo
Motor drive optionalNo
Rated permanent current Iu160A
Number of poles4
Suitable for fusesOther
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA115928R1001 | OS160GBS40N1K
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Conditioned rated short-circuit current Iq
80kA
Cable entry
Other
Type of electrical connection of main circuit
Bolt connection
Type of control element
Long turning handle
Version as safety switch
Version as emergency stop installation
Version as main switch
Motor drive integrated
Rated operation power at AC-23, 400 V
132kW
Equipped with connectors
Suitable for front mounting
Position control element
Right
Suitable for busbar mounting
Rated short-time withstand current lcw
5kA
With error protection
Suitable for floor mounting
Motor drive optional
Rated permanent current Iu
160A
Number of poles
4
Suitable for fuses
Other
Max. rated operation voltage Ue AC
1000V
