1SCA116717R1001 | OS160GD02P
Code: 1982329
ManufacturerABB
Catalog number1SCA116717R1001
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019488042
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Motor drive integratedNo
Type of control elementLong turning handle
Version as emergency stop installationNo
Conditioned rated short-circuit current Iq80kA
Rated short-time withstand current lcw5kA
Suitable for front mountingNo
Version as main switchYes
Position control elementLeft
Type of electrical connection of main circuitBolt connection
Suitable for floor mountingNo
Motor drive optionalNo
Suitable for busbar mountingYes
Version as safety switchYes
With error protectionNo
Equipped with connectorsYes
Rated operation power at AC-23, 400 V132kW
Rated permanent current Iu160A
Number of poles2
Suitable for fusesNH000
Max. rated operation voltage Ue AC1000V
