Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Cable entryOther
Rated permanent current Iu125A
Version as safety switchYes
Suitable for fuses22x58 mm
Rated short-time withstand current lcw5kA
Motor drive integratedNo
Motor drive optionalNo
Suitable for busbar mountingYes
Max. rated operation voltage Ue AC1000V
Type of control elementLong turning handle
Conditioned rated short-circuit current Iq80kA
Number of poles2
Suitable for front mountingNo
Suitable for floor mountingNo
Version as emergency stop installationNo
Version as main switchYes
Position control elementFront side
Rated operation power at AC-23, 400 V110kW
With error protectionNo
Type of electrical connection of main circuitBolt connection
Equipped with connectorsYes
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA116726R1001 | OS125GF11P
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Cable entry
Other
Rated permanent current Iu
125A
Version as safety switch
Suitable for fuses
22x58 mm
Rated short-time withstand current lcw
5kA
Motor drive integrated
Motor drive optional
Suitable for busbar mounting
Max. rated operation voltage Ue AC
1000V
Type of control element
Long turning handle
Conditioned rated short-circuit current Iq
80kA
Number of poles
2
Suitable for front mounting
Suitable for floor mounting
Version as emergency stop installation
Version as main switch
Position control element
Front side
Rated operation power at AC-23, 400 V
110kW
With error protection
Type of electrical connection of main circuit
Bolt connection
Equipped with connectors
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
