1SCA116753R1001 | OS160GB03K
Code: 1982342
ManufacturerABB
Catalog number1SCA116753R1001
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019488370
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Type of electrical connection of main circuitBolt connection
Cable entryOther
Motor drive integratedNo
Conditioned rated short-circuit current Iq80kA
Type of control elementLong turning handle
Version as main switchYes
Version as safety switchYes
Version as emergency stop installationNo
Rated short-time withstand current lcw5kA
Suitable for floor mountingNo
Suitable for front mountingNo
Rated operation power at AC-23, 400 V132kW
With error protectionNo
Suitable for busbar mountingYes
Motor drive optionalNo
Position control elementLeft
Equipped with connectorsYes
Rated permanent current Iu160A
Number of poles3
Suitable for fusesOther
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA116753R1001 | OS160GB03K
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Type of electrical connection of main circuit
Bolt connection
Cable entry
Other
Motor drive integrated
Conditioned rated short-circuit current Iq
80kA
Type of control element
Long turning handle
Version as main switch
Version as safety switch
Version as emergency stop installation
Rated short-time withstand current lcw
5kA
Suitable for floor mounting
Suitable for front mounting
Rated operation power at AC-23, 400 V
132kW
With error protection
Suitable for busbar mounting
Motor drive optional
Position control element
Left
Equipped with connectors
Rated permanent current Iu
160A
Number of poles
3
Suitable for fuses
Other
Max. rated operation voltage Ue AC
1000V
