Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Rated operation power at AC-3, 400 V-kW
Depth82.5mm
Width150mm
Number of auxiliary contacts as normally open contact0
Height110.5mm
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu160A
Degree of protection (IP), front sideIP00
Conditioned rated short-circuit current Iq-kA
Number of poles2
Version as emergency stop installationNo
Rated operating voltage1000 - 1000V
Number of auxiliary contacts as change-over contact0
Version as safety switchNo
Rated short-time withstand current lcw8kA
Width in number of modular spacings-
Number of switches1
Type of control elementLong turning handle
Type of electrical connection of main circuitBolt connection
InterlockableNo
Version as main switchYes
Rated operation power at AC-23, 400 V88kW
Motor drive integratedNo
Version as maintenance-/service switchYes
Suitable for front mounting 4-holeNo
Suitable for floor mountingNo
Suitable for distribution board installationNo
Colour control elementBlack
Suitable for front mounting centreNo
Max. rated operation voltage Ue AC1000V
Suitable for intermediate mountingNo
Motor drive optionalNo
Voltage release optionalNo
Degree of protection (NEMA)Other
Switching power at 400 V88kW
Rated permanent current at AC-23, 400 V160A
With pre-assembled cablingNo
Version as reversing switchNo
Rated permanent current at AC-21, 400 V200A
Device constructionComplete device in housing
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA120508R1001 | OT160EV02P
