Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V-kW
Rated permanent current Iu160A
Depth107mm
Version as emergency stop installationNo
Number of auxiliary contacts as change-over contact0
Number of poles3
InterlockableNo
Height150mm
Width145.5mm
Type of control elementLong turning handle
Number of auxiliary contacts as normally open contact0
Degree of protection (IP), front sideIP00
Motor drive integratedNo
Number of switches1
Conditioned rated short-circuit current Iq-kA
Type of electrical connection of main circuitBolt connection
Width in number of modular spacings-
Rated operating voltage1000 - 1000V
Version as safety switchNo
Version as main switchYes
Version as maintenance-/service switchYes
Rated short-time withstand current lcw8kA
Colour control elementBlack
Suitable for front mounting centreNo
Device constructionComplete device in housing
Voltage release optionalNo
Suitable for front mounting 4-holeNo
Rated permanent current at AC-23, 400 V160A
Rated permanent current at AC-21, 400 V200A
Switching power at 400 V88kW
Motor drive optionalNo
Suitable for floor mountingNo
With pre-assembled cablingNo
Rated operation power at AC-23, 400 V88kW
Suitable for distribution board installationNo
Degree of protection (NEMA)Other
Suitable for intermediate mountingNo
Version as reversing switchNo
Max. rated operation voltage Ue AC1000V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA120527R1001 | OT160EV12K
