1SCA123054R1001 | OS125GD13N2P
Code: 1982527
ManufacturerABB
Catalog number1SCA123054R1001
TypeFuse switch disconnector
CategoryFuse switch disconnector
EAN code6417019539515
Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Type of electrical connection of main circuitBolt connection
Motor drive integratedNo
Conditioned rated short-circuit current Iq80kA
Cable entryOther
Suitable for floor mountingNo
Suitable for front mountingNo
Rated short-time withstand current lcw5kA
Rated operation power at AC-23, 400 V110kW
Version as main switchYes
Type of control elementLong turning handle
Version as emergency stop installationNo
Version as safety switchYes
Equipped with connectorsYes
With error protectionNo
Position control elementFront side
Suitable for busbar mountingYes
Motor drive optionalNo
Rated permanent current Iu125A
Number of poles4
Suitable for fusesNH000
Max. rated operation voltage Ue AC1000V
