Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
InterlockableYes
Conditioned rated short-circuit current Iq-kA
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as change-over contact0
Number of switches1
Type of electrical connection of main circuitScrew connection
Rated permanent current Iu-A
Version as emergency stop installationNo
Type of control elementLong turning handle
Rated operating voltage1000 - 1000V
Motor drive integratedNo
Number of poles3
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Degree of protection (IP), front sideIP20
Version as main switchYes
Version as safety switchNo
Voltage release optionalNo
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Version as reversing switchNo
Colour control elementBlack
Device constructionBuilt-in device plug-in technique
Degree of protection (NEMA)1
Motor drive optionalNo
Suitable for floor mountingNo
Rated short-time withstand current lcw15kA
Rated permanent current at AC-21, 400 V400A
Rated permanent current at AC-23, 400 V400A
Suitable for front mounting 4-holeYes
Switching power at 400 V220kW
Max. rated operation voltage Ue AC1000V
Suitable for front mounting centreNo
Version as maintenance-/service switchYes
Rated operation power at AC-23, 400 V220kW
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA123582R1001 | OT400E03YP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Interlockable
Conditioned rated short-circuit current Iq
-kA
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as change-over contact
0
Number of switches
1
Type of electrical connection of main circuit
Screw connection
Rated permanent current Iu
-A
Version as emergency stop installation
Type of control element
Long turning handle
Rated operating voltage
1000 .. 1000V
Motor drive integrated
Number of poles
3
Rated operation power at AC-3, 400 V
-kW
Number of auxiliary contacts as normally open contact
0
Degree of protection (IP), front side
IP20
Version as main switch
Version as safety switch
Voltage release optional
Suitable for distribution board installation
Suitable for intermediate mounting
Version as reversing switch
Colour control element
Black
Device construction
Built-in device plug-in technique
Degree of protection (NEMA)
1
Motor drive optional
Suitable for floor mounting
Rated short-time withstand current lcw
15kA
Rated permanent current at AC-21, 400 V
400A
Rated permanent current at AC-23, 400 V
400A
Suitable for front mounting 4-hole
Switching power at 400 V
220kW
Max. rated operation voltage Ue AC
1000V
Suitable for front mounting centre
Version as maintenance-/service switch
Rated operation power at AC-23, 400 V
220kW
