Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Depth205mm
Width585mm
Number of auxiliary contacts as normally open contact2
Number of auxiliary contacts as change-over contact0
Number of poles3
Rated operating voltage1000 - 1000V
Number of auxiliary contacts as normally closed contact2
Height819mm
Degree of protection (IP), front sideIP65
Conditioned rated short-circuit current Iq-kA
Rated permanent current Iu600A
Motor drive integratedNo
Number of switches1
Type of control elementLong turning handle
Version as emergency stop installationNo
InterlockableYes
Rated operation power at AC-3, 400 V-kW
Width in number of modular spacings-
Suitable for front mounting 4-holeNo
Suitable for front mounting centreNo
Colour control elementBlack
Switching power at 400 V315kW
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC1000V
Version as reversing switchNo
Device constructionComplete device in housing
Rated permanent current at AC-23, 400 V540A
Degree of protection (NEMA)Other
Suitable for distribution board installationYes
Rated permanent current at AC-21, 400 V-A
With pre-assembled cablingNo
Version as safety switchYes
Suitable for floor mountingNo
Voltage release optionalNo
Version as maintenance-/service switchYes
Version as main switchYes
Rated operation power at AC-23, 400 V315kW
Rated short-time withstand current lcw20kA
Motor drive optionalNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA144287R1001 | OTA600P3B
