Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •ABB
Technical specifications
Width156.5mm
Height211mm
Depth135mm
Rated permanent current Iu630A
Conditioned rated short-circuit current Iq-kA
Number of auxiliary contacts as normally closed contact0
Type of electrical connection of main circuitBolt connection
Rated operation power at AC-3, 400 V-kW
InterlockableNo
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Version as main switchYes
Degree of protection (IP), front sideIP20
Version as safety switchNo
Version as maintenance-/service switchYes
Type of control elementOther
Rated operating voltage1000 - 1000V
Number of switches1
Width in number of modular spacings-
Motor drive integratedNo
Number of poles2
Version as emergency stop installationNo
Suitable for front mounting 4-holeYes
Rated short-time withstand current lcw-kA
Suitable for front mounting centreNo
Suitable for floor mountingNo
Rated operation power at AC-23, 400 V-kW
Motor drive optionalNo
Suitable for distribution board installationYes
Device constructionBuilt-in device fixed built-in technique
Voltage release optionalNo
Rated permanent current at AC-21, 400 V-A
Suitable for intermediate mountingNo
Switching power at 400 V-kW
With pre-assembled cablingNo
Rated permanent current at AC-23, 400 V-A
Max. rated operation voltage Ue AC-V
Degree of protection (NEMA)1
Version as reversing switchNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SCA158230R1001 | OTDC630F02
