1SDA075628R1 | XT4V-D 250 MCS-UL/CSA Im=2500 3p F F
Code: 1983820
ManufacturerABB
Catalog number1SDA075628R1
TypeSwitch disconnector
CategorySwitch disconnector
EAN code8015644796051
Details
- •Low-voltage industrial components
- •Switch disconnector
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Number of switches-
Version as emergency stop installationNo
Motor drive integratedNo
InterlockableYes
Rated operation power at AC-3, 400 V-kW
Type of electrical connection of main circuitBolt connection
Conditioned rated short-circuit current Iq-kA
Number of auxiliary contacts as normally closed contact0
Degree of protection (IP), front sideIP20
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally open contact0
Version as main switchYes
Rated operating voltage0 - 600V
Version as maintenance-/service switchNo
Rated operation power at AC-23, 400 V-kW
Suitable for front mounting centreNo
Rated short-time withstand current lcw-kA
Suitable for floor mountingNo
Degree of protection (NEMA)1
Motor drive optionalYes
Device constructionBuilt-in device fixed built-in technique
Switching power at 400 V-kW
Voltage release optionalYes
Suitable for distribution board installationYes
Rated permanent current at AC-23, 400 V-A
Colour control elementWhite
Suitable for front mounting 4-holeNo
Suitable for intermediate mountingNo
Version as reversing switchNo
Version as safety switchNo
Rated permanent current at AC-21, 400 V250A
Rated permanent current Iu250A
Number of poles3
Max. rated operation voltage Ue AC600V
