Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally open contact0
Version as main switchYes
Type of electrical connection of main circuitBolt connection
Suitable for floor mountingNo
Rated operation power at AC-3, 400 V-kW
Version as maintenance-/service switchNo
Version as emergency stop installationNo
Number of switches0
Degree of protection (IP), front sideIP30
Motor drive integratedNo
Number of auxiliary contacts as normally closed contact0
Rated operating voltage600 - 600V
Colour control elementOther
Number of poles3
Rated permanent current Iu800 A
Rated operation power at AC-23, 400 V-kW
Rated short-time withstand current lcw42kA
InterlockableYes
Conditioned rated short-circuit current Iq-kA
Version as safety switchNo
Type of control elementPush button
Number of auxiliary contacts as change-over contact0
Suitable for distribution board installationYes
Suitable for front mounting 4-holeNo
Suitable for front mounting centreNo
Motor drive optionalYes
Max. rated operation voltage Ue AC600V
Suitable for intermediate mountingNo
Voltage release optionalYes
Rated permanent current at AC-21, 400 V800 A
Device constructionBuilt-in device fixed built-in technique
Degree of protection (NEMA)Other
Version as reversing switchNo
Rated permanent current at AC-23, 400 V800 A
Switching power at 400 V-kW
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA079548R1 | E1.2B-A/MS 800 3p F F
