Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Type of electrical connection of main circuitBolt connection
Rated operation power at AC-3, 400 V-kW
Conditioned rated short-circuit current Iq-kA
Version as main switchYes
Degree of protection (IP), front sideIP30
Type of control elementPush button
Number of poles3
Number of auxiliary contacts as normally closed contact0
Rated operating voltage600 - 600V
Number of auxiliary contacts as change-over contact0
Motor drive integratedNo
Rated permanent current Iu800 A
Number of auxiliary contacts as normally open contact0
Version as emergency stop installationNo
Number of switches0
InterlockableYes
Version as maintenance-/service switchNo
Rated short-time withstand current lcw50kA
Rated operation power at AC-23, 400 V-kW
Version as safety switchNo
Colour control elementOther
Voltage release optionalYes
Suitable for distribution board installationYes
Version as reversing switchNo
Suitable for front mounting centreNo
Suitable for floor mountingNo
Motor drive optionalYes
Suitable for front mounting 4-holeNo
Rated permanent current at AC-21, 400 V800 A
Suitable for intermediate mountingNo
Device constructionBuilt-in device slide-in technique (withdrawable)
Max. rated operation voltage Ue AC600V
Rated permanent current at AC-23, 400 V800 A
Degree of protection (NEMA)Other
Switching power at 400 V-kW
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA079558R1 | E1.2N-A/MS 800 3p WMP
