Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •ABB
Technical specifications
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu2500A
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally open contact0
Number of poles4
Degree of protection (IP), front sideIP30
Rated operating voltage600 - 600V
Number of auxiliary contacts as change-over contact0
Number of switches0
Type of electrical connection of main circuitBolt connection
InterlockableYes
Motor drive integratedNo
Conditioned rated short-circuit current Iq-kA
Version as maintenance-/service switchNo
Rated permanent current at AC-21, 400 V2500A
Version as safety switchNo
Suitable for front mounting centreNo
Device constructionBuilt-in device slide-in technique (withdrawable)
Version as reversing switchNo
Rated operation power at AC-23, 400 V-kW
Rated short-time withstand current lcw85kA
Colour control elementOther
Suitable for distribution board installationYes
Version as main switchYes
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC600V
Voltage release optionalYes
Motor drive optionalYes
Switching power at 400 V-kW
Version as emergency stop installationNo
Suitable for floor mountingNo
Suitable for front mounting 4-holeNo
Type of control elementPush button
Rated permanent current at AC-23, 400 V2500A
Degree of protection (NEMA)Other
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA079650R1 | E4.2V-A/MS 2500 4p WMP
