Details
- •Domestic switching devices
- •Socket outlet
- •1 KOM
- •ABB
Technical specifications
Nominal voltage220V
ModelBritish Standard
Mounting methodFlush mounted (plaster)
With hinged lidNo
Halogen freeYes
ColourAnthracite
Number of units1
Nominal current15A
LockableNo
Label space/information surfaceNo
With signal lampNo
Number of ports USB-A-
With on/off switchNo
Surface protectionDecor
Frequency50 - 60Hz
Connection typeScrewed terminal
Eject-mechanismNo
With enhanced contact protectionYes
Number of phases2
Material qualityThermoplastic
MaterialPlastic
Over voltage protectionNo
Rotated central insertNo
Rated fault current-mA
Surface finishingMatt
Fault current protectionNo
Type of fasteningSnap mounting (engagement)
Suitable for degree of protection (IP)IP20
Insulated mountingNo
With loop through functionNo
Width of device44mm
Height of device44mm
Impact strengthIK04
Imprint/indicationNone
RAL-number (similar)-
With miniature fuseNo
TransparentNo
Special power supplyOther
Concurrently switching neutral conductorNo
Number of modules (module system)2
With function lightingNo
Depth of device73mm
With orientation lightingNo
Number of socket outlets switchable0
IFTTT support availableNo
Protective contactSquare
Compatible with Amazon AlexaNo
Number of active pins (flat)0
Min. depth of built-in installation box-mm
Number of active pins (round)0
Number of active contacts (square)3
Anti-bacterial treatmentNo
With built-in bluetooth speakerNo
For heavy conditions (according to VDE)No
Maximum current rating of USB power supply-A
Compatible with Google AssistantNo
Number of loop throughs-
Compatible with Apple HomeKitNo
Number of ports USB-C-
Metallic colourNo
With Wi-Fi signal repeaterNo
Compliant with UK Building Regulations Part MNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CLA223700N1801 | N2237 AN
