Details

  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •1 KOM
  • •ABB

Technical specifications

Built-in depth69mm
Voltage typeAC/DC
Pollution degree3
Connectable conductor cross section solid-core0,75 - 35mm²
Ambient temperature during operating-25 - 55°C
Over voltage category3
Explosion-proofNo
Rated insulation voltage Ui440V
Flush-mounted installationNo
Degree of protection (IP)IP20
Frequency50 - 60Hz
Current limiting class3
Additional equipment possibleNo
Connectable conductor cross section multi-wired0,75 - 25mm²
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V-kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Rated voltage230V
Width in number of modular spacings1
Number of protected poles1
Concurrently switching neutral conductorNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated current2A
Release characteristicB
Number of poles (total)1
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
